最大工作高度Max working height

2120mm

最大装载高度Max pin height

1865 mm

最大卸载高度Max Dumping height

1405 mm

最大倾卸距离Max Dumping distance

505mm

最大卸载角度Max Dumping Angle

35°

总高度Total height

1350 mm

离地间隙Ground clearance

121 mm

轴距Wheel base

无铲斗总长度Overall length without bucket

1495 mm

总宽度Total width

990 mm

铲斗宽度Bucket width

1080mm

带铲斗总长度Total length with bucket

2245 mm

折叠踏班不带铲斗总长度overall length  without the bucket after  folding the pedal.

1990 mm

发动机Engine

润通R420

百利通13.5HP

科普192（独立油箱）

额定功率Rated Power (KW)

10.5Kw/3600rpm

10Kw/3600rpm

10Kw/3600rpm

转速Rotating speed (rpm)

3600

3600

3000

噪声Noise (Db)

≤95

≤95

≤95

液压系统Hydraulic System

压力Pressure (Mpa)

0-17

0-17

0-17

属具流量Flow rate

0-18L

0-18L

0-15L

工作负载Operating Load

180 Kg(含属具自重)

180 Kg(含属具自重)

180 Kg(含属具自重)

铲斗容量Bucket Capacity

0.13m³

0.13m³

0.13m³

最大提升力Max Lifting Force

200 Kg

200 Kg

200 Kg

行驶速度Travel Speed

0-3Km/h

0-3Km/h

0-3Km/h

工作重量Operating Weight

630kg

630kg

630kg

油Oil

燃油箱Fuel tank

6.5L

6.5L

8.5L

发动机机油Engine oil

1.7L

1.7L

1.7L

液压油箱
Hydraulic tank

30L

30L

30L
