项目

item

Metric

system

British

system

最大工作高度

Maximum working height

2400mm

94.84inch

最大销轴高度

Maximum pin height

2200mm

86.61inch

最大卸料高度

Maximum discharge height

2000mm

78.74inch

最高点卸料距离

Maximum discharge distance

800mm

31.4inch

铲斗摆角

Bucket swing Angle

55°

55°

铲斗卸料角度

Bucket discharge Angle

40°

40°

离去角

Departure Angle

20°

20°

总高

Total height

1350mm

53.14inch

离地间隙

Ground height

100mm

3.93inch

轴距

Wheelbase

860mm

33.85inch

无铲斗长度

No bucket length

2020mm

79.52inch

总宽

Total width

1200mm

47.24inch

斗宽

Bucket width

1200mm

47.24inch

总长(带铲斗)

Total length (with bucket)

2600mm

102.36inch

Engine

额定功率（HP）

Rated power (HP)

Briggs&Stratton 23Hp

标定转速（rpm）

Rated speed (rpm)

3600

噪音（Db）

Noise (Db)

≤95

燃油箱容积(L)

Fuel tank volume(L)

30 L

液压油箱容积(L)

Hydraulic tank volume(L)

20 L

Hydraulic system

系统压力（Mpa）

System Pressure (Mpa)

25MPa=250bar=3626psi

标配流量(L/Min)

Standard flow(L/Min)

33L/min

行走泵流量(L/Min)

Traveling pump flow(L/Min)

75L/min

90L/min

补油泵流量(L/Min)

Replenishment pump flow(L/Min)

10L/min

13L/min

工作系统(L/Min)

Working system(L/Min)

44L/min

44L/min

Tyre type

人字形工程胎

Herringbone engineered tire

18*8.5-8

Performance parameter

装载量

Carrying capacity

430Kg(62%

tipping load)

947.9Lb

铲斗容积

Bucket volume

0.17 m3

6ft³

最大举升力

Maximum lift

430Kg

947.9Lb

速度

speed

0-7 Km/h

0-4.3 mlie/h

设备净重：

Net weight:

950Kg

2094.39Lb

爬坡角度

Angle of climb

20degree
