整机操作重量Overall Operating Weight

6000KG

运输尺寸Transport Dimension

长×宽×高 L*W*H

7600×2100×2900mm

轴距 Wheel base

2250mm

最小离地间隙 Min. Ground Clearance

300mm

装载斗容 Bucket Capacity

1.3m3

掘起力Breakout Force

38KN

装载举升能力Loading Lifting Capacity

2500KG

铲斗卸载高度Bucket Dumping Height

3500mm

后挖斗容Backhoe Capacity

0.3m³

最大挖掘深度Max. Digging Depth

4000mm

可选最大挖掘深度Optional Max. Digging Depth

5000mm-5500mm（挖臂伸缩Digging boom telescopic）

挖斗回转角Swing Angle of backhoe

170o

最大牵引力Max. Pulling Force

39KN

轮距Wheel tread

2470mm

轴距Wheel base

1600mm

发动机Engine

型号Model

YUNNEI YN38GBZ Turbo Engine

型式Type

单列、直喷、四冲程、水冷

In Line，Direct injection，Four-Stroke，Water Cooling

额定功率Rated Power

76KW

可选发动机Optional engine

欧五4G33TC-75L常柴55.2KW

EPA4/欧五科勒KDI2504TCR发动机55KW

EPA4康明斯55KW发动机QSF2.8     EPA4康明斯QSF3.8

75KW康明斯4BT3.9-C100   玉柴YCF36100-S500欧五74KW

转向系统Steering System

转向角Steering Angle

±40 o

最小转弯半径Min. turning radius

4600mm

系统压力Pressure of the system

12Mpa

驱动桥Axle

型式Type

四轮驱动Four wheel drive

轮边减速型式Final Reducer

一级轮边减速Single Stage Final Reducer

传动系统Transmission System

变矩器Torque Converter

型号Model

265

型式Type

单级、单相三元件Single-stage Three Elements

冷却方式Cooling Method

油冷压力循环Oil-cooling Pressure Circulation

变速箱Gearbox

型式Type

动力换档Power Transmission

档位数Optional Gears

前进4档，后退4档Four Gears Ahead, Four Gears Astern

最高车速Max. Speed

30Km/h

轮胎Tyre

规格Model

16/70-20

制动系统Brake System

行车制动Service Brake

气顶油钳盘制动Air Over Oil Caliper Brake

外置式External Type

自调节Self-regulation

自平衡Self-balance

驻车/紧急制动Emergency Brake

操纵力实施制动Operation Power Implementing brake

手操纵力解除制动Manual Operation Power Terminating Brake

液压系统Hydraulic System

液压系统压力Pressure of Hydraulic System

22Mpa
