整机操作重量

Overall Operating Weight

6600KG

运输尺寸Transport Dimension

长×宽×高mm L*W*H

7800×2200×3000

最小离地间隙

Min. Ground Clearance

350mm

装载斗容 Bucket Capacity

1.5m3(2200mm宽width)

掘起力Breakout Force

38KN

装载举升能力

Loading Lifting Capacity

2800KG

铲斗卸载高度

Bucket Dumping Height

3600mm

铲斗卸载距离

Bucket Dumping Distance

1062mm

反铲斗容

Backhoe Capacity（Width）

0.3m3(620mm宽width)

最大挖掘深度

Max. Digging Depth

4000mm

Optional Digging Depth可选挖深

5000mm-5500mm（挖臂带伸缩）

挖斗回转角

Swing Angle of backhoe

190o

最大牵引力

Max. Pulling Force

39KN

Wheel base轴距

1600mm

Wheel tread轮距

2680mm

发动机Engine

品牌/型号Brand/Model

YUNNEI YN48GBZ Turbo engine涡轮增压发动机

型式Type

单列、直喷、四冲程、水冷

In Line，Direct injection，Four-Stroke，Water Cooling

额定功率Rated Power

92KW

可选发动机Optional Engine

YUCHAI/YCD4J22T-115（85KW））

YUCHAI/YCD4T33T6-115(国三90KW）

CUMMINS 74KW 4BT3.9-C100

CUMMINS EURO3 75KW QSB3.9-C100

EURO5 YUCHAI or EPA4 CUMMINS

转向系统Steering System

转向角Steering Angle

±36 o

系统压力

Pressure of the system

12Mpa

驱动桥Axle

型号Model

大轮边桥Big Wheel Hub Reducer

轮边减速型式Final Reducer

一级轮边减速Single Stage Final Reducer

传动系统Transmission System

变矩器Torque Converter

型号Model

280

型式Type

单级、单相三元件Single-stage Three Elements

冷却方式Cooling Method

油冷压力循环Oil-cooling Pressure Circulation

变速箱Gearbox

型式Type

定轴式动力换档Fixed Shaft Power Transmission

档位数Optional Gears

前进4档，后退4档Four Gears Ahead, Four Gears Astern

最高车速Max.Speed

38Km/h

轮胎Tyre

规格Model

16/70-24

前轮气压

Pressure of Front wheel

0.22 Mpa

后轮气压

Pressure of Back Wheel

0.22 Mpa

制动系统Brake System

行车制动Service Brake

气顶油钳盘制动Air Over Oil Caliper Brake

外置式External Type

自调节Self-regulation

自平衡Self-balance

驻车/紧急制动

Emergency Brake

操纵力实施制动Operation Power Implementing brake

手操纵力解除制动Manual Operation Power Terminating Brake

液压系统Hydraulic System

液压系统压力

Pressure of Hydraulic System

22Mpa
