Overall Operating Weight

8000KG

Transport Dimension

 L*W*H

8000×2200×2900mm

轴距 Wheel base

2250mm

最小离地间隙

Min. Ground Clearance

300mm

装载斗容 Bucket Capacity

1.5m3

掘起力Breakout Force

38KN

装载举升能力

Loading Lifting Capacity

2800KG

铲斗卸载高度

Bucket Dumping Height

2800mm

铲斗卸载距离

Bucket Dumping Distance

1062mm

铲挖深度 Digging Depth

52mm

反铲斗容

Backhoe Capacity（Width）

0.35m3(620mm)

最大挖掘深度

Max. Digging Depth

4100mm

挖斗回转角

Swing Angle of backhoe

190o

最大牵引力

Max. Pulling Force

39KN

发动机Engine

型号Model

YUCHAI

型式Type

单列、直喷、四冲程、水冷

In Line，Direct injection，Four-Stroke，Water Cooling

额定功率Rated Power

85KW

发动机选配：Optional engine

DONGFENG CUMMINS 75KW/  CUMMINS 92KW/ CUMMINS Euro3 75KW

转向系统Steering System

转向角Steering Angle

±36 o

最小转弯半径

Min. turning radius

6581mm

系统压力

Pressure of the system

12Mpa

驱动桥Axle

品牌Brand

肥城云宇桥FEICHENG YUNYU

主传动类型

Main Transmission Type

双减速

Double Reduction

轮边减速型式Final Reducer

一级轮边减速Single Stage Final Reducer

额定载重

Rated Loader of Axle

4/18.5t

传动系统Transmission System

变矩器Torque Converter

型号Model

YJ280

型式Type

单级、单相三元件Single-stage Three Elements

冷却方式Cooling Method

油冷压力循环Oil-cooling Pressure Circulation

变速箱Gearbox

型式Type

定轴式动力换档Fixed Shaft Power Transmission

档位数Gears

前进2档，后退2档Two Gears Ahead, Two Gears Astern

最高车速Max.Speed

30Km/h

轮胎Tyre

规格Model

（F）14-17.5前轮

（R）19.5L-24后轮

前轮气压

Pressure of Front wheel

0.22 Mpa

后轮气压

Pressure of Back Wheel

0.22 Mpa

制动系统Brake System

行车制动Service Brake

气顶油钳盘制动Air Over Oil Caliper Brake

外置式External Type

自调节Self-regulation

自平衡Self-balance

驻车/紧急制动

Emergency Brake

操纵力实施制动Operation Power Implementing brake

手操纵力解除制动Manual Operation Power Terminating Brake

液压系统Hydraulic System

液压系统压力

Pressure of Hydraulic System

22Mpa

挖斗挖掘力

Digging Power of Excavator Grab

46.5KN

铲斗掘起力

Digging Power of Dipper

31KN

铲斗提升时间

Bucket Lifting Time

5.4S

铲斗下降时间

Bucket Lowering Time

3.1S

铲斗卸料时间

Bucket Discharge Time

2.0S
